PRO Z790-P WIFI DDR4 ATX Motherboard, LGA 1700 Socket, Intel Z790 Chipset, 4x DIMM Slots up to 5333+MHz, 3x PCIe (5.0/4.0) x16 Slots, 4x M.2 - 6x SATA, Wi-Fi 6E, 2.5G LAN, DP, HDMI, Type-C, Max 128GB RAM.

Introduction

The MSI PRO Z790-P WiFi DDR4 is a professional-grade ATX motherboard built around the Intel Z790 chipset and the LGA 1700 socket, compatible with 12th, 13th, and 14th Gen Intel Core, Pentium Gold, and Celeron processors. Unlike gaming-focused boards, the PRO series emphasizes productivity, stability, and efficiency—delivering robust DDR4 support, PCIe 5.0 expansion, Wi-Fi 6E, and enterprise-ready features all at a strong value point.

Power Design

It leverages a 14+1+1 Duet Rail power system with 55 A DrMOS MOSFETs, Core Boost, and Memory Boost enhancements. Dual 8-pin CPU power connectors and extended VRM heatsinks with 7 W/mK thermal pads ensure efficient cooling and reliable power delivery for serious workloads.

Memory

Supports up to 256 GB of DDR4 memory across four DIMM slots. Overclocking beyond DDR4-5333 (OC) is supported, delivering strong performance potential while maintaining DDR4 platform affordability.

Expansion & Storage

Expansion includes a PCIe 5.0 ×16 slot for next-gen GPUs, along with additional PCIe 4.0 ×16 (x4 mode) and PCIe 3.0 ×1 slots. For storage, you'll find three M.2 PCIe 4.0 ×4 slots (with built-in “M.2 Shield Frozr” heatsinks) and six SATA 6 Gb/s ports, all supporting RAID 0/1/5/10.

Networking

Features dual connectivity with Intel 2.5 GbE LAN and onboard Wi-Fi 6E plus Bluetooth 5.2 for fast, reliable wired and wireless networking.

I/O & Diagnostic Features

The rear I/O includes USB 3.2 Gen 2×2 Type-C (20 Gbps), multiple USB 3.2 Gen 2/Gen 1 ports, HDMI, DisplayPort, and a BIOS Flash button. Internally, the board provides EZ Debug LEDs, front-panel USB headers, RGB/ARGB headers, and a Tuning Controller connector for fine-tuning performance.

Cooling & Build Quality

Thermal features include extended VRM heatsinks, thermal MOSFET pads rated 7 W/mK, additional choke pad coverage, and M.2 Shield Frozr—designed for sustained performance in demanding applications.

Notable Trade-offs

While the PRO Z790-P WiFi is well-built and stable, some reviews note cost optimization: legacy but reliable ALC897 audio, vertical SATA port layout, and occasional network quirks requiring reboots—common on budget-friendly boards.

Benefits

This motherboard strikes an excellent balance of modern connectivity, future-proof expansion, and solid build quality—all anchored around DDR4 affordability. Ideal for professionals or productivity builders who want high-end features without unnecessary extras.
